| Price | 110 |
| MOQ | 1 |
| Delivery Time | 5 days for samples |
| Brand | RION |
| Place of Origin | China |
| Certification | CE |
| Model Number | TL735-232 |
| Packaging Details | carton box with sponge |
| Payment Terms | T/T,PAYPA |
| Supply Ability | 5000/month |
| Place of Origin | China | Packaging Details | carton box with sponge |
| Model Number | TL735-232 | Azimuth accuracy | <0.5° |
| Supply Ability | 5000/month | Measure range | ±10~180DU° |
| Zero output | 2.5V | Certification | CE |
| Brand Name | RION | Payment Terms | T/T,PAYPA |
| Price | 110 | Delivery Time | 5 days for samples |
| Measure axis | X/XY Axis | Minimum Order Quantity | 1 |
| Power-on start time | 0.5S | Resolution | 0.01~0.05° |
SCA120T VOLTAGE TYPE DUAL AXIS INCLINOMETER ±180° TILT SENSOR WITH 0–5V OUTPUT
The SCA110T/SCA120T is a high-performance tilt sensor designed to measure inclination angles relative to the horizontal plane with exceptional accuracy. Utilizing MEMS-based micro-electromechanical pendulum technology, it converts static gravity field changes into analog voltage outputs (0–5V), enabling real-time attitude monitoring for industrial and safety-critical applications.
Dual-Axis Measurement (SCA120T) / Single-Axis (SCA110T)
Wide Measuring Range: ±1° to ±180° (customizable)
High Precision: Resolution up to 0.01°
Robust Design:
IP67 protection (dustproof/waterproof)
Extreme Temperature Tolerance: –40°C to +85°C
Anti-Vibration >2000g | EMI-Resistant
Wide Voltage Input: 9–36V DC
Compact Size: 90×40×26mm (easy integration)
Heavy Machinery: Leveling for construction vehicles, mining equipment, and oil rigs.
Infrastructure Monitoring: Bridge deflection, dam tilt, and shield tunneling alignment.
Safety Systems: High-altitude platform stabilization, anti-tip protection.
Precision Control: Medical equipment, geological instruments, and pipe jacking.
Industrial Automation: Conveyor belt tilt correction, robotic arm positioning.
Non-Contact Measurement: Long lifespan, no mechanical wear.
Plug-and-Play: Voltage output simplifies integration with PLCs, SCADA, or IoT systems.
Reliable in Harsh Environments: Ideal for dust, moisture, and high-vibration scenarios.
Technical Support: Customizable ranges, OEM/ODM services available.
Structure: Clear headings for quick scanning (Features/Applications/Benefits).
Technical Depth: Emphasizes MEMS technology and rugged specs (IP67, 2000g).
Application Focus: Links features to real-world use cases (e.g., mining, bridges).
Marketing Edge: "Why Choose" section highlights competitive advantages.
Conciseness: Removes redundancy while preserving critical details.
▶ PARAMETERS
|
SCA110/SCA120T |
CONDITION PARAMETER |
UNIT |
|||||
|
|
|
±10 |
±30 |
±60 |
±90 |
±180 |
° |
|
Measure axis |
|
X/XY |
X/XY |
X/XY |
X/XY |
X |
Axis |
|
Zero output |
0° output |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
V |
|
Resolution |
|
0.01 |
0.01 |
0.02 |
0.03 |
0.05 |
° |
|
Measure accuracy |
@25℃ |
0.03 |
0.05 |
0.06 |
0.08 |
0.1 |
° |
|
ZeroTemp.coefficient |
-40~85℃ |
±0.006 |
±0.006 |
±0.006 |
±0.006 |
±0.006 |
°/℃ |
|
Sensitivity temp-coeffi |
-40~85℃ |
≤100 |
≤100 |
≤100 |
≤100 |
≤100 |
ppm/℃ |
|
Power-on start time |
|
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
S |
|
Response frequency |
20Hz |
||||||
|
EMC |
According to EN61000和GBT17626c |
||||||
|
MTBF |
≥98000 hours/times |
||||||
|
Insulation Resistance |
≥100MΩ |
||||||
|
Impact resistance |
100g@11ms,3 Axis Direction (Half Sinusoid) |
||||||
|
Anti-vibration |
10grms,10~1000Hz |
||||||
|
Protection grade |
IP67 |
||||||
|
Cables |
Standard as 1-meter length, wear-resistant, oil-proof, wide temperature, shielded cable 4 * 0.4mm2 |
||||||
|
Weight |
≤220g (including 1 meter cable) |
||||||
▶ELECTRICAL PARAMETERS
|
|
CONDITION |
MIN |
TYPICAL |
MAX |
UNIT |
|
|
Power supply |
Standard |
9 |
12 |
24 |
36 |
V |
|
|
Optional |
|
5 |
|
V |
|
|
Working current |
|
|
30 |
|
mA |
|
|
Output overload |
10 |
|
|
kΩ |
||
|
|
Capacitive |
|
|
20 |
nF |
|
|
Working temp |
|
-40 |
|
+85 |
℃ |
|
|
Store temp. |
|
-40 |
|
+85 |
℃ |
|
