| Price | 3700-9000USD/TON |
| MOQ | negotiable |
| Delivery Time | 30 Days |
| Brand | MTSCO |
| Place of Origin | CHINA |
| Certification | ISO;PED |
| Model Number | MTSCOHET58 |
| Packaging Details | Plywood Case |
| Payment Terms | T / T ; L / C |
| Supply Ability | 300 Tons / Month |
| Place of Origin | CHINA | Packaging Details | Plywood Case |
| Inspection | 100% | Material | 300 Series |
| Standard | ASTM A213 | Model Number | MTSCOHET58 |
| Supply Ability | 300 Tons / Month | Certification | ISO;PED |
| Surface | Pickling | Brand Name | MTSCO |
| Payment Terms | T / T ; L / C | Price | 3700-9000USD/TON |
| Delivery Time | 30 Days | Length | 18 m |
| Minimum Order Quantity | negotiable | Technique | cold rolled |
| Application | oil & gas industry , chemical industry , electric power , boiler and heat exchanger , machinery , metallurgy , sanitary construction etc . |
S30400 Annealed Surface U Bend Stainless Steel Heat Exchanger Tube
Heat Exchanger Tube:
Our heat exchanger tube with pickling and annealing surface is very popular in boilers and heat exchangers industry, water heater industry, air-conditioning industry, etc. This kind of seamless tube has a very important position in our all products.
Heat exchanger tube, choose MTSCO!
Heat Exchanger Tube Chemical Composition :
Austenitic:
TP310S(0Cr25Ni20,
2520)
TP304(0Cr18Ni9)
904L
(00Cr20Ni25Mo4.5Cu
,
UNS
N08904)
TP347(0Cr18Ni11Nb)
TP347H(1Cr19Ni11Nb)
TP321(0Cr18Ni10Ti)
TP304L(00Cr19Ni10)
TP316(0Cr17Ni12Mo2)
TP316L(00Cr17Ni14Mo2)
| C(max) | Si(max) | P(max) | S(max) | Cr | Ni | Mo | Ti | |
| TP304/1.4301 | 0.080 | 1.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-10.5 | ||
| TP304L/1.4307 | 0.035 | 1.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-12.0 | ||
| TP304H/1.4948 | 0.04-0.10 | 1.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-12.0 | ||
| TP316/1.4401 | 0.080 | 1.00 | 0.045 | 0.030 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |
| TP316L/1.4404 | 0.035 | 1.00 | 0.045 | 0.030 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |
| TP316Ti/1.4571 | 0.080 | 1.00 | 0.045 | 0.030 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 0.7>5x(C+N) |
| TP321/1.4541 | 0.080 | 1.00 | 0.045 | 0.030 | 17.0-19.0 | 9.0-12.0 | 0.7>5x(C+N) | |
| TP317L/1.4449 | 0.080 | 1.00 | 0.045 | 0.030 | 18.0-20.0 | 11.0-14.0 | 3.0-4.0 | |
| TP347H/1.4912 | 0.04-0.10 | 1.00 | 0.045 | 0.030 | 17.0-19.0 | 9.0-13.0 | ||
| TP309S/1.4833 | 0.080 | 1.00 | 0.045 | 0.030 | 22.0-24.0 | 12.0-15.0 | 0.75 | |
| TP310S/1.4845 | 0.080 | 1.00 | 0.045 | 0.030 | 24.0-26.0 | 19.0-22.0 | 0.75 |
Heat Exchanger Tube Specifications :
| DN | NPS(Inch) | D(mm) | SCH5S | SCH10S | SCH40S | STD | SCH40 | SCH80 | XS | SCH80S | SCH160 | XXS |
| 6 | 1/8 | 10.30 | - | 1.24 | 1.73 | 1.73 | 1.73 | 2.41 | 2.41 | 2.41 | - | - |
| 8 | 1/4 | 13.70 | - | 1.65 | 2.24 | 2.24 | 2.24 | 3.02 | 3.02 | 3.02 | - | - |
| 10 | 3/8 | 17.10 | - | 1.65 | 2.31 | 2.31 | 2.31 | 3.20 | 3.20 | 3.20 | - | - |
| 15 | 1/2 | 21.30 | 1.65 | 2.11 | 2.77 | 2.77 | 2.77 | 3.73 | 3.73 | 3.73 | 4.78 | 7.47 |
| 20 | 3/4 | 26.70 | 1.65 | 2.11 | 2.87 | 2.87 | 2.87 | 3.91 | 3.91 | 3.91 | 5.56 | 7.82 |
| 25 | 1 | 33.40 | 1.65 | 2.77 | 3.38 | 3.38 | 3.38 | 4.55 | 4.55 | 4.55 | 6.35 | 9.09 |
| 32 | 1 1/4 | 42.20 | 1.65 | 2.77 | 3.56 | 3.56 | 3.56 | 4.85 | 4.85 | 4.85 | 6.35 | 9.70 |
| 40 | 1 1/2 | 48.30 | 1.65 | 2.77 | 3.68 | 3.68 | 3.68 | 5.08 | 5.08 | 5.08 | 7.14 | 10.15 |
| 50 | 2 | 60.30 | 1.65 | 2.77 | 3.91 | 3.91 | 3.91 | 5.54 | 5.54 | 5.54 | 8.74 |
11.07 |
Heat Exchanger Tube Advantages
a) Advanced technology of cold draw machine
b) Advanced annealing machine
c) Better mechanical property
d) More precise dimension
e) Perfect inspection method and inspection equipment etc
Heat
Exchanger
Tube Process
:
1
.
We
use
Cold
Drawn
technology
to
produce
U
bend
tube
2.
U
bend
tubes
produce
will
accordance
to
customer's
drawings
3
.
To
avoid
oxidation,
inert
gas
(Argon)
is
passed
through
tubes
ID
at
the
required
flow
rate
4
.
The
radius
is
checked
for
its
OD
and
wall
thinning
with
the
recommended
specification
5
.
We'll
choose
three
different
positions
or
as
customers
require
to
make
sure
tubes
quality.
We'll
do
physical
properties
and
micro-structure
test
6
.
Visual
inspection
for
waviness
and
cracks
is
done
with
Dye
Penetrant
Test
7
.
Each
tube
is
then
hydro
tested
at
the
recommended
pressure
to
check
for
leakage
About MTSCO:
Who MTSCO is?
MTSCO established in 2006, during many years’ development, now becomes a large and professional industrial piping system provider, serving customers from more than 100 countries and regions.
What products can MTSCO provide?
What materials can MTSCO provide?
Austenitic: 304/L/H/N,316/L/H/N/Ti,321/H,309/H,310S,347/H,317/L904L
Duplex steel: 31803,32205,32750,32760
Nickel Alloy:
UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230, R30556
UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926
UNS N04400, N05500
Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH
Nickel: N4/UNS N02201, N6/UNS N02200
How can MTSCO service customers?
MTSCO's ISO9001 Quality System is issued by TUV. Our full and professional inspection reports contain two parts, one is self-inspection of the requirements beyond ISO9001, which is 100% inspected by our own QC; another is 100% inspected by professional QC teams.
